Posted on October 9, 2026 by John White

A knock that repeats once per revolution is a timing clue. It points toward something that occurs at one place on a rotating or looping part. It does not name that part. The phrase "per revolution" is itself ambiguous, because the track loop, a roller, the idler and the sprocket all complete revolutions at different rates. The first job is to determine which revolution the knock follows.

If the knock tracks a marked position on the belt, a belt-related feature is a candidate. If it tracks a component's rotation, that component is. Neither result is a diagnosis. Hold the machine and obtain qualified service when the knock is regular, persistent or accompanied by vibration, visible damage or any change in how the machine runs.

Which revolution is it?

At steady speed, each rotating part has its own repeat interval:

The track loop repeats once per complete lap of the belt, which takes the longest.
The sprocket and idler each repeat once per turn of those components.
A roller repeats once per turn of its own, shorter circumference.

All of these speed up and slow down with travel speed, so a knock that follows speed does not by itself identify the source. What separates them is the interval. A knock once per track lap will be far less frequent than one tied to a roller. Counting the knocks against a reference lap is more reliable than judging by ear.

The sources I reviewed give symptom-level descriptions, not a procedure for this. Fortis HD and similar guides describe rollers with seized bearings developing flat spots, and one AFTparts article on undercarriage noise describes rhythmic squeaking from flat spots or damaged bearings in carrier rollers. A track supplier's sprocket guide describes rhythmic clicking or snapping, and sometimes clunking or vibration felt in the cab, when sprocket and drive lugs do not mesh smoothly. These support treating roller, idler, sprocket and track-belt features as separate branches. None describes a once-per-lap knock.

Marking a position and counting laps

You can test whether the knock follows the belt without touching a moving track. All marking and measurement must be done with the machine stopped and secured under the applicable procedure.

Choose a visible feature on the belt that cannot be confused with another, such as a distinctive tread block or a defect already present, and photograph it. Note its position.
Photograph the same feature relative to a fixed reference on the machine so you can compare later.
Have the operator run the machine under normal authorized operation, with everyone else outside the danger area. Do not approach a moving track, and do not reach in to see the feature.
Record the operation, ideally with video and audio, from a safe position that shows the marked feature and a fixed reference.
Review the recording: do the knocks coincide with the marked feature reaching the same point on each lap?

Do not move the machine just to test the idea, and do not mark a track while it is moving. If you cannot watch the feature safely, do not try. A qualified technician can assess it under the machine procedure.

If the knock does not line up with the marked feature, that points away from a single belt feature but does not clear the belt. A lap-synchronous result also does not tell you what the feature is, only that its position matters.

Record the timing map

A consistent record separates a repeating pattern from random noise.

Record	What to note	What it does not show
Direction	Forward, reverse or both, and whether the knock changes with direction	The cause
Speed	The speed range, and whether the interval between knocks shortens as speed rises	Which component is involved
Interval	Time between knocks at steady speed, measured from a recording	Whether the interval matches a belt lap or a roller turn
Regularity	Whether the knock is steady, intermittent or disappears for stretches	A random versus defect-driven cause
Side	Left, right or both tracks	Whether the cause is shared
Load and surface	Paved or soft ground, slope, attachments or load	That the surface is the cause
Apparent location	Front, centre or rear of the undercarriage, judged from outside	The exact contact point
Marked feature	Whether the knock coincides with the marked belt feature passing a fixed reference	What the feature is
Vibration	Whether it is felt through the machine, and whether it matches the knock	Where it originates

Compare the branches

Branch	Evidence that would support it	What leaves it open
A belt feature, such as a damaged lug, an embedded-metal irregularity or a local deformation	The knock coincides with the marked belt position; visible damage, bulge, cracking or lifted rubber at that spot	No visible feature at the matching position
A roller with a flat spot or seized bearing	A rhythmic knock matching a roller's rotation; a visibly flattened or non-turning roller; wet residue or abnormal wear	Rollers turn freely and look normal
The idler	Knock matched to idler rotation; wear, damage or uneven running of the idler	Idler appears sound
The sprocket or drive engagement	Clicking, snapping or clunking at drive engagement; rounded or damaged sprocket teeth and damaged drive lugs	Intact sprocket and lugs
Debris or packed material	Material around the rollers, idler or drive area, with the noise changing after approved cleaning	Clean undercarriage
Random undercarriage noise	No fixed interval; varying timing, direction or location	A repeating pattern

Mid-roller flat spots deserve their own note. Camso's guidance for agricultural tracks says a flat spot on a mid-roller wheel may indicate the wheel stopped turning, and says root-cause investigation should follow. That supports checking roller condition when a regular knock is heard. It does not make any roller the answer here.

Keep to bounded decisions

Monitor under normal authorized operation only when the knock is occasional, there is no visible damage, no vibration change and no abnormal track position, and you can keep recording safely.
Stop and obtain qualified service when the knock is regular or growing, tracks a marked belt position, comes with visible bulging, cracking, lifted rubber, exposed material, damaged rollers, idler or drive lugs, or when the machine feels different to drive.
Treat any condition you cannot see safely from outside the undercarriage as unresolved, not as clear.

Do not lift or block the machine, release tension, remove guards or reach into the track frame to look for the source. Do not run the machine to reproduce the knock. Do not name a defect from a sound.

Fitment information if a track is replaced

If qualified service identifies a damaged rubber track, a knock report does not identify the part. Provide:

Machine manufacturer, exact model, serial number and configuration from the machine plate or documentation.
All size and identification markings on the existing track.
Photographs of the outer tread, inner surface and sidewall, including the marked feature and any damage.
Your timing map and video notes.
The qualified service finding, if available.

AFTparts' Rubber Tracks collection is relevant once service has named a Rubber Tracks component and you have that information. Do not choose a replacement from a noise symptom, tread pattern or outside width. This article does not verify any listing or interchangeability.
