Merlo Undercarriage Parts: Fitment Help

We do not currently list a part whose product page names a Merlo machine. This page explains how to identify the undercarriage parts your machine needs so our team can check whether an equivalent we stock is a match. We will not guess at fitment; every match is confirmed by size or part number.

What to send us

  • The model and serial number from the machine's plate.
  • For rubber tracks, the size moulded inside the track: width, pitch and number of links.
  • For rollers, idlers and sprockets, any number cast or stamped on the part, plus tooth and bolt-hole counts for sprockets.
  • Photos of the old parts if numbers are worn. Send everything through Check Fitment on Contact Us.

Reading a rubber track size

A track stamp such as 320 Ɨ 86 Ɨ 52 means 320 mm wide, 86 mm pitch and 52 links. Letters added to the size usually describe the tread, so width, pitch and links are the numbers that decide fit.

Signs a part is due

  • Sprocket teeth that look hooked or pointed.
  • A track that needs tension more often than before.
  • Flat spots on rollers or noise from the undercarriage.
  • Cuts that expose steel cord.

Before you order

Gather the machine serial, the track stamp and any cast numbers on the steel parts. With those details, fit can be checked against store listings instead of being guessed.

Storage and off-season care

For seasonal storage, wash out the frame, ease off track tension as the manual permits and keep the machine off soft or frozen ground. Inspect everything again before the next job.

Undercarriage parts at a glance

The sprocket drives the track, the front idler guides it and holds tension, bottom rollers carry the load and carrier rollers hold up the upper run. Because each is numbered separately, matching by number avoids most ordering mistakes.

Choosing a tread pattern

If a size is offered in several treads, all of them fit the same machine; pick the one that suits your ground, or stay with the pattern you have now.

Inspection before you order

Check track sag against the operator manual, look for exposed cords or missing lugs, and spin-check rollers for leaks or flat spots. In Canadian winters, clean packed snow and mud from the frame before parking so it does not freeze around the rollers.

Related guides and collections

See undercarriage parts by machine guide.

FAQ

Do you have parts for the Merlo?
Not as a named listing today. Send your sizes and part numbers and we will check whether a stocked part matches.

Can I order by machine model alone?
It is safer to order by track size or part number, because machines can change undercarriage between series.
